SA164F 4-WAY 'F' SPLITTER AMPLIFIER

Features

• LED Power Indicator
• SMD design
• Electrical storm and static protection
• F-Type sockets
• Continually adjustable preset gain control from
• Min: Ch2 +4dB, Ch 10 + 8dB to Max: +10dB

Specifications

• 240V 50Hz 2.0A Mains supply - 44-860MHz TV Signal Booster Ga in: 16dB to two outlets
• Noise figure 6dB typical
• High Output: 8 channels 98 dBuv
• Australian Made and Approved
