Product Features

• Maximum 80A Rated
• Voltage: (Un) AC 240V(415V)
• Rated frequency: 50(60)Hz
• Phase: Three Phase Starting
• Current: 0.4%lb Insulation
• Performance: AC voltage withstand 2kV for 1 minute lmpulse voltage withstand 6kV --1,2/50ps waveform
• Accuracy Class Class 1.0
• Dimensions: 125mm(L) 88mm(H) 73mm(W)
• Installation method: DIN rail
• Humidity: Less than 75%
• Operating temperature: -25fC^+55°C
• Storage temperature: -30T>+65°C
• Display: Analog
• Standards: IEC61063
