• Complete din rail mount MCB,
• Available in 6A, 10A, 16A, 20A, 25A, 32A, 40A, 50A & 63A.

► Higher kA rating: 10kA. ► Complete din rail mount MCB. ► Designed by electricians for electricians. ► Free tripping mechanism, cannot be held on against a fault.

Pulset’s range of miniature circuit breakers all conform with the IEC60898 and AS/NZS 4898:1997 and is approved by the Australian Standards. (Approval Number N11193) The range comes with a Pulset life time guarantee.

We are distributor and supply worldwide!

You can call us if any queries to place your order for MCBs.

• MCBs Available in 6A, 10A, 16A, 20A, 25A, 32A, 40A, 50A & 63A.

1 pole Miniature Circuit Breaker available in following AMPs with us.

• 16Amp 10KA 1 Pole MCB
• 6Amp 10KA 1 Pole MCB
• 10Amp 10KA 1 Pole MCB
• 20Amp 10KA 1 Pole MCB
• 25Amp 10KA 1 Pole MCB
• 32Amp 10KA 1 Pole MCB
• 40Amp 10KA 1 Pole MCB
• 50Amp 10KA 1 Pole MCB
• 63Amp 10KA 1 Pole MCB

Available Amperage: 6, 10, 16, 20, 25, 32, 40, 50 & 63 Amp

Poles: 1, 2, 3 & 4 Module

Curves: b, c & d

Rated Voltage AC: 240V/415V

Electric Life: Over 6,000 operations

Mechanical Life: (O-C) Over 20,000 operations

Ambient Temperature: -5 up to 40oC

Rated Frequency: 50 (60) Hz.

Weight: 1 Pole: 125g, 3 Pole: 375g

****Please note brands supplied will be either Pulset, Transco or Tesla. All are Australian Certified.****
