Dream Machine Special Edition


- 1.7 GHz quad-core processor
- Dual WAN ports (10G SFP+ and 2.5GbE RJ45)
- (8) GbE RJ45 ports, including (6) 802.3af PoE and (2) 802.3at PoE+ LAN ports
- (1) 10G SFP+ LAN port
- (1) 1.3" LCM colour touchscreen for at-a-glance network monitoring
- Customizable internet threat filtration and traffic identification for enhanced network security
- Quick, Bluetooth-powered setup via the UniFi Network web application or mobile app 1U-sized, rack-mountable device
- Connect a SmartPower Redundant Power System to create an uninterruptible network
- Integrated security gateway and UniFi Protect-ready NVR that supports compatible 3.5" HDDs
- 128 GB integrated storage for full UniFi OS Application experience
Enterprise Grade for Home & Business
The Dream Machine Special Edition (UDM SE) is an enterprise-grade UniFi OS Console capable of helping home and business owners alike seamlessly scale and manage their networks with high-speed, dual-WAN connectivity (10G SFP+ and 2.5GbE RJ45 ports), a Gigabit, PoE switch, and a network video recorder (NVR) with 128 GB of internal storage. Powered by UniFi OS, the UDM SE gives you full control of all your UniFi devices, including access points, Protect cameras, Talk phones, and Access readers. It's also a future-proof console since it will be able to run all upcoming UniFi OS applications. Engineered for end-to-end simplicity, the UDM SE features an integrated Bluetooth radio that streamlines the initial setup and configuration process, which can be completed in minutes with the UniFi Network application (web or mobile).

UniFi Enterprise Architecture Evolves with UniFi OS
The new UniFi OS portal provides streamlined access to all of your UniFi OS consoles and applications.






Product Specs
442.4 x 43.7 x 285.6 mm
4.95 kg
Aluminium CNC, SGCC steel
SGCC steel rack mount
Quad-Core ARM® Cortex®-A57 at 1.7 GHz
4 GB DDR4
16 GB eMMC
Integrated 128 GB SSD
3.5 Gbps*
*Measured with iPerf3
50W
(1) Universal AC input, 100-240VAC, 4.4A Max, 50/60 Hz
(1) USP-RPS DC input, 52VDC, 3.94A
AC/DC, Internal, 240W
100 to 240VAC
Ethernet
Bluetooth
(1) WAN: 2.5 GbE RJ45 port
(8) LAN: 1 GbE RJ45 ports
(1) WAN: 10G SFP+
(1) LAN: 10G SFP+
(2) PoE+ IEEE 802.3at (pair A 1, 2+; 3, 6-)
(6) PoE IEEE 802.3af (pair A 1, 2+; 3, 6-)
15.4W
30W
44 to 57V
50 to 57V
Air: ± 15 kV, contact: ± 8 kV
(1) 1.3" touchscreen
Bootup animation: bootup in progress
Firmware upgrade icon: firmware upgrading
Factory reset
-10 to 40° C
5 - 95% noncondensing
CE, FCC, IC
White: Link / Activity
White: Link / Activity
White: Disk Activity
Amber: Disk Error
Blue: Ready
Ubiquiti Dream Machine Special Edition, All-In-One Unifi Solution, 8x Gbe PoE RJ45 Ports, 3.5" HDD Bay
SKU: NW-UDMSE
